Automatic Nail Polish Filling And Capping Machine

Nail Polish Filling & Plugging and Capping Machine with functions of automatic filling, loading brush and capping. The whole machine adopts PLC control, with the function of no bottle no filling, no brush no cover, easy operation and adjustment conveniently.

Nail Polish Filling & Plugging and Capping Machine with functions of automatic filling, loading brush and capping. The filling device adopts bottle positioning mechanism to solve the problem of large size deviation of the nail polish filling glass container that the filling nozzle can not be put into the container. The storage bucket uses the way of pressure feeding by separating from the main machine. The volume of the bucket can be customized by customers and place the storage bucket randomly. That alternate use of multiple storage buckets effectively shorten the time for replacement of different materials. Adopt the approach of mechanical arm fetching cap, pre-spin to cover, which solve the problem of brush poor positioning, and cannot cover .Capping device with a torque adjusting device, capping torque can be adjusted according to customer’s requirement. The whole machine adopts PLC control, with the function of no bottle no filling, no brush no cover, easy operation and adjustment conveniently.

Main technical parameter:

Main motor power: 0.75KW

Production Capacity : 40pcs/min

Filling volume: 5-20ml

Air supply pressure: 0.6-0.8Mpa

Dimension: 175*1650*1820mm

Built on decades of industry experience supporting the cosmetics manufacturing sectors with our in-line packaging solutions, VKPAK has brought together all of our proven technologies for the first time in a single Monoblock Packaging Machine dedicated to the packaging of nail polish in small and extra-small containers and vials.

Through a process of continual evolution and constant dialogue with our customers the VKPAK offers significant productivity enhancements that will benefit manufacturers and boost efficiency. Its return on investment completely justifies itself compared to most machines on the market.

Perfect for the packaging of mascara and lip gloss, the VKPAK’s monoblock design meticulously encompasses all aspects of your core production needs, from containers multi-feeding, double servo-driven viscose filling, capping, over capping, sealing, labeling, discharging and QC.

This nail polish filling machine combines mechanical / pneumatic / automatic technology as a new innovation generation of special Machine in nail polish liquid filling with high automation / rate of finished products / stability and widely adaptability etc. characteristics, so that it is the favor of the numerous customers. It becomes perfect & maturity day by day during consummate constantly in years.

This machine is suitable to fill the abnormity vials such as rotundity / flat / prism etc. with low filling measurement warp and suitable to many kinds of stoppers & caps, so that it has the obvious advantages compared with this kind machines worldwide. It is completely met the GMP regulation by means of the powerful advantages of our company in design / manufacture for non-standard products.

When the bottles in an even row which sent by conveyor reach filling part, filling nozzles will go deep down to inside of bottle and begin to fill. The nozzle will go up slightly to bottleneck, then filling stops. The conveyor will convey bottles to equal-index plate. The plate makes bottles do intermittent motion in the function of cam indexer. Bottles arrive at plugging part, then go to capping part. When finish capping, bottles will be sent to the next process by conveyor.
